| d |
l +1 |
zakres |
dk |
dm |
index |
szt. |
| 3,0 |
5,0 |
1,5-3,0 |
6,0
-0,4 |
1,7 |
10.700.300.050 |
500 |
| 6,0 |
2,0-4,0 |
10.700.300.060 |
500 |
| 8,0 |
3,5-6,0 |
10.700.300.080 |
500 |
| 10,0 |
5,0-7,5 |
10.700.300.100 |
500 |
| 12,0 |
7,0-9,0 |
10.700.300.120 |
500 |
| EN AW - 5719 [AlMg5] |
 3,1 mm |
 660N |
 900N |
| 3,2 |
6,0 |
1,5-3,5 |
6,2
-0,4 |
1,9 |
10.700.320.060 |
500 |
| 8,0 |
3,0-5,5 |
10.700.320.080 |
500 |
| 10,0 |
5,0-7,5 |
10.700.320.100 |
500 |
| 12,0 |
7,0-9,0 |
10.700.320.120 |
500 |
| 16,0 |
9,0-13,0 |
10.700.320.160 |
500 |
| EN AW - 5719 [AlMg5] |
3,3 mm |
660N |
1100N |
| 4,0 |
6,0 |
1,5-3,5 |
7,5
-0,5 |
2,0 |
10.700.400.060 |
500 |
| 8,0 |
2,0-5,5 |
10.700.400.080 |
500 |
| 10,0 |
5,0-7,0 |
10.700.400.100 |
500 |
| 12,0 |
6,5-9,0 |
10.700.400.120 |
500 |
| 16,0 |
8,5-12,5 |
10.700.400.160 |
500 |
| 18,0 |
12,0-14,5 |
10.700.400.180 |
500 |
| EN AW-5754 [AlMg3] |
4,1 mm |
1120N |
1420N |
|
|
| d |
l +1 |
zakres |
dk |
dm |
index |
szt. |
| 4,8 |
10,0 |
4,0-6,5 |
9,0
-0,5 |
2,7 |
10.700.480.100 |
500 |
| 12,0 |
6,0-8,0 |
10.700.480.120 |
500 |
| 16,0 |
8,0-12,0 |
10.700.480.160 |
500 |
| 20,0 |
12,0-15,5 |
10.700.480.200 |
500 |
| EN AW - 5754 [AlMg3] |
4,9 mm |
1480N |
1950N |
| 5,0 |
8,0 |
2,0-5,0 |
9,3
-0,5 |
2,7 |
10.700.500.080 |
500 |
| 10,0 |
4,0-6,5 |
10.700.500.100 |
500 |
| 12,0 |
6,0-8,0 |
10.700.500.120 |
500 |
| 14,0 |
7,5-10,0 |
10.700.500.140 |
500 |
| 16,0 |
8,0-12,0 |
10.700.500.160 |
500 |
| 18,0 |
11,5-13,5 |
10.700.500.180 |
500 |
| 20,0 |
12,0-15,5 |
10.700.500.200 |
500 |
| 25,0 |
15,0-20,0 |
10.700.500.250 |
500 |
| 30,0 |
20,0-25,0 |
10.700.500.300 |
500 |
| 35,0 |
25,0-30,0 |
10.700.500.350 |
250 |
| EN AW-5754 [AlMg3] |
5,1 mm |
1650N |
2000N |
|
